Toughened Glass
Toughened Glass
Toughened Glass
Toughened Glass
Toughened Glass
Toughened Glass
Toughened Glass

Toughened Glass

REXI Toughened Glass is glass after the heat treatment process. It is characterized by the formation of compressive stress on the surface layer, mechanical strength and thermal shock resistance is improved, and has a special debris status.



Product Details

REXI Toughened Glass is glass after the heat treatment process. It is characterized by the formation of compressive stress on the surface layer, mechanical strength and thermal shock resistance is improved, and has a special debris status.

In China toughened glass factory, material used in the production should have quality that is consistent with the corresponding product standards. For special requirements, the material used in the production’s quality should be determined by both China toughened glass supplier and costumer.


1

2

3

4


FEATURES:

The aperture is generally not less than the thickness of the glass, if it need to be drilling, the distance from the edge of the hole to the edge of the product should not be less than 2 times of the thickness of the glass, the distance between two holes should not be less than 2 times the thickness, the distance between the edge of the hole and the corners should not be less than 6 times of glass thickness. So toughened glass price is related to the shape and processing.

-5 times harder than ordinary float glass, stronger resistance to thermal breakage than annealed or heat strengthened glass.

-Once breakage occurs, the glass disintegrates into small cubical fragments, which are relatively harmless to human body.

-It withstands abrupt temperature change of 220 Centigrade.

-Sizes are produced as per customer request. Once tempered, it cannot be cut down.


APPLICATION:

REXI Toughened Glass cut to size can avoid potential cuts and injuries as a result of broken glass.

-  All doors (sliding, swing, etc.)

-  Windows (side, stair and bathroom etc.)

-  Curtain Walls and Storefronts

-   Automotive windows shields

-   Shower Enclosures


China Balustrade Glass M6

5


6


STANDARS:

China GB15763.2-2005 AND 9963-1998; Europe EN 12600:2002, 16 CFR 1201; America ASTM C1048; UK BS 6206:1995



SPECIFICATIONS:

For China toughened glass manufacturers, packaging should be used wooden boxes or cases, the cases should be easy loading, unloading and transportation. Each case needs to be packed with stuff of the same thickness and size.

Glass Types: Float Glass, Low E Glass, Patterned Glass

Glass Colors: Clear, Extra Clear, Bronze, Grey, Blue and Green, etc.

Thickness: 3mm, 3.2mm, 4mm, 5mm, 6mm, 8mm, 10mm, 12mm, 15mm and 19mm, etc.

Max. Size: 12,000mm * 3,300mm

Min. Size: 100mm * 300mm

Delivery Time:     In Three weeks after order confirmation.


7
